Indicator	Unit	66 ＂	72 ＂
Steel wheel width	mm	1670	1855
Steel wheel diameter	mm	600	600
Vibration force	kg	3540	3880
Vibration frequency	Vpm	2600	2600
Weight	kg	800	900
Length	mm	1848	2000
Width	mm	900	900
Height	mm	610	610

Structural characteristics:

Compaction roller: Steel rollers are usually used, and the surface can be smooth or angular. Smooth roller is suitable for compacting asphalt pavement and can make the road surface smooth and even; The sheep horn roller has a better compaction effect on soil and other materials, increasing the contact area and friction with the material, and improving the compaction depth and density.

Vibration mechanism: Built in vibration device, usually driven by a hydraulic motor to rotate an eccentric block to generate vibration, which is transmitted to the compressed material through rollers to enhance the compaction effect.

Connection device: Equipped with a quick connection mechanism that matches the skid steer loader, it can be easily and quickly installed on the skid steer loader to achieve quick replacement and improve operational efficiency.

Working principle: The skid steer loader provides power and walking function for the vibratory roller.

During operation, the rollers of the vibratory roller roll forward or backward under the drive of the skid steer loader. At the same time, the hydraulic system drives the vibration mechanism to generate high-frequency vibration, and the vibration energy is transmitted to the road surface or other compressed materials, reducing the gaps between material particles and bringing them closer to each other, thus achieving the purpose of compaction. By adjusting the pressure and flow rate of the hydraulic system, the frequency and amplitude of vibration can be controlled to adapt to different compaction conditions.

Performance advantages:

Good compaction effect: It has hydraulic vibration or oscillation function, high excitation force, can effectively improve compaction density, ensure compaction quality, and is suitable for various road construction projects and foundation compaction operations.

High flexibility: With the characteristics of a skid steer loader, it has a small turning radius and can operate flexibly in narrow spaces. It can easily adapt to complex construction environments such as narrow urban roads, residential roads, and construction sites. It can also be compacted close to sidewalks, walls, or roadsides.

Easy to operate: With the help of the control system of the skid steer loader, the operation is relatively simple. The driver can easily control walking and vibration functions through devices such as handles in the cab, reducing labor intensity.

Strong multifunctionality: The skid steer loader can quickly replace various attachments. In addition to the vibration roller function, it can also replace other attachments such as buckets and crushers to achieve various operations such as excavation, loading, and crushing, improving equipment utilization and cost-effectiveness.

Application Scenario:

Road construction: It can be used for compacting the base and surface layers of highways and urban roads, including the compaction of asphalt pavement and cement stabilized soil and other base materials. It is also suitable for compaction operations in local areas of road repair projects.

Site leveling: In site leveling operations at construction sites, industrial sites, parking lots, and other places, backfill soil can be compacted to ensure the stability of the site foundation.

Landscape engineering: used for compaction of garden paths, squares, etc., capable of completing compaction tasks in a small space without affecting the surrounding green landscape.

Farmland construction: It can be used to compact farmland roads, field work lanes, etc., and can also be used for compacting small embankments and channel foundations in agricultural water conservancy projects.
